What's in the box 6x3x2 ft Powder Coated?

  • 4 x 1.5ft x 21” Short Panels
  • 4 x 3ft x 21” Long Panels
  • 4 x U-Shape Strips
  • 8 x Corners
  • 1 x User Manual
  • 5 x Long Nuts
  • 25 x Wingnuts, Screws & Washers
  • 85 x Nuts, Screws & Washers
  • 8 x Support Bars
  • 4 x Covers
  • 85 x Hole Covers

Check our Installation Video for the Carpathen Modular Raised Garden Bed

Installation Steps for Standard Rectangular Shape

Step 1 - Install (C) corners on each end of two (B) long panels. Use (E) nuts, screws, and washers by placing them in the first row of holes, as shown in the images below.

Step 2 - Connect two (A) short panels to each of the two (B)+(C) ensembles. Fasten with (E) nuts, screws, and washers. Use the first row of holes, as shown in the images above. Place the washer on the inside. Cover the second row of corner holes with (J) hole covers.

Step 3 - Connect the two (A) +(B)+(C) structures using two (B) long panels, ensuring edges overlap properly. Inside each overlap, place an (F) U-shaped strip and secure with (D) screws, wingnuts, and washers. Leave the tirst and titth holes empty as they will have support bars to be connected in the next step.

Step 4 - Connect (H) support bars two by two by using (G) threaded screws. The resulting support bars will be connected to rows 1 and 5 on the inside of the U-strip bars. For row 1, attach the (H) support bar by placing a (1) cover over the top outside of the raised garden bed. Use (D) screws and washers to connect the support bars.

Installation Steps for 2 x Mini Shape

Step 1 - Install (C) corners on each end of four (A) short panels. Use (E) nuts, screws, and washers by placing them in the first row of holes, as shown in the images below.

Step 2 - Connect two (A)+(C) ensembles with two (B) panels. Fasten with (E) nuts, screws, and washers. Use the first row of holes, as shown in the images below. Place the washer on the inside. Repeat the same process for the other two (A) +(C) ensembles.

Cover the second row of corner holes with (J) hole covers.

Installation Steps for I-Shape

Step 1 - Install (C) corners on each end of two (A) short panels. Use (E) nuts, screws, and washers by placing them in the first row of holes, as shown in the images below.

Step 2 - Connect two (B) long panels to each of the (A) +(C) ensemble. Fasten with (E) nuts, screws, and washers. Use the first row of holes, as shown in the images below. Place the washer on the inside. Cover the second row of corner holes with

(J) hole covers.

Step 3 - Connect the two (A)+(B)+(C) structures by using two (A) short panels, ensuring edges overlap properly. Inside each overlap, place an (F) U-shaped strip and secure with (D) screws, wingnuts, and washers. Leave the first, third, and fifth holes empty as they will have support bars to be connected in the next step.

Step 4 - Connect (H) support bars to rows 1, 3, and 5. Position them on the inside of the (F) U-strip bars. For row 1, attach the (H) support bars by placing a (I) cover over the top outside of the raised garden bed. Use (D) screws and washers to secure all connected support bars.

Installation Steps for L-Shape

Step 1 - Install (C) corners on each end of two (A) short panels. Use (E) nuts, screws, and washers by placing them in the first row of holes, as shown in the images below.

Step 2.1 - Connect two (B) long panels to one of the (A)+(C) ensemble. Fasten with (E) nuts, screws, and washers. Use the first row of holes, as shown in the images below.

Place the washer on the inside.

Step 2.2 - Connect the (A)+(B)+(C) structure with one (B) panel and one (A) panel, ensuring edges overlap properly. Inside each overlap, place an (F) U-shaped strip and secure with (D) screws, wingnuts, and washers. Leave the first, third, and fifth holes empty as they will have support bars to be connected in the next steps.

Step 2.3 - Connect one (A) short panel and one (B) long panel to the other (A) +(C) ensemble.

Fasten with (E) nuts, screws, and washers. Use the first row of holes, as shown in the images below.

Place the washer on the inside.

Step 3.1 - Connect the two (A) +(B) +(C) ensembles with one (C) corner. Use (E) nuts, screws, and washers by placing them in the SECOND row of holes, as shown in the images below. Cover the second row of corner holes with (J) hole covers.

Step 3.2 - Connect the two (A) +(B)+(C) ensembles with one (C) corner. Use (E) nuts, screws, and washers by placing them in the FIRST row of holes, as shown in the images below. Cover the second row of corner holes with (J) hole covers.

Step 4 - Connect three (H) support bars to rows 1, 3, and 5; position these on the inside of the (F) U-strip bars. For row 1, attach the (H) support bars by placing a (I) plastic cover over the top outside of the raised garden bed. Use (D) screws and washers to secure all connected support bars.

Installation Steps for P-Shape

Step 1 - Install (C) corners on each end of one (A) short panel and one (B) long panel. Use (E) nuts, screws, and washers by placing them in the first row of holes, as shown in the images below.

Step 2.1 - Connect one (B) long panel and one (A) short panel to the (A) +(C) ensemble. Fasten with (E) nuts, screws, and washers. Use the first row of holes, as shown in the images below. Place the washer on the inside.

Step 2.2 - Connect the (A) +(B)+(C) structure with one (B) panel and one (A) panel, ensuring edges overlap properly. Inside each overlap, place an (F) U-shaped strip and secure with (D) screws, wingnuts and washers. On the (B)+(B) side of the structure, leave the first, third, and fifth holes empty as they will have support bars to be connected in the next steps.

Step 2.3 - Connect one (A) short panel and one (B) long panel to the other (B)+(C) ensemble. Fasten with (E) nuts, screws, and washers. Use the first row of holes, as shown in the images below. Place the washer on the inside.

Step 3.1 - Connect the (A)+(B)+(C) ensembles with one (C) corner. Use (E) nuts, screws, and washers by placing them in the SECOND row of holes, as shown in the images below.

Step 3.2 - Connect the (A)+(B)+(C) ensembles with one (C) corner and one (F) U-shaped strip. Secure with (D) screws, wingnuts, and washers by placing them in the FIRST row of holes (on the corner) , as shown in the images below. Leave the first, third, and fifth holes empty as they will have support bars to be connected in the next steps. Cover the second row of corner holes with (J) hole covers.

Step 4 - Connect three (H) support bars to rows 1, 3, and 5; position these on the inside of the (F) U-strip bars. For row 1, attach the (H) support bars by placing a (I) cover over the top outside of the raised garden bed. Use (D) screws and washers to secure all connected support bars.

Installation Steps for Square-Shape

Step 1 - Connect four (A) short panels with four (B) long panels as shown in the above picture, ensuring edges overlap, place an (F) U-shaped strip and secure with (D) screws , wingnuts , and waashers by placing a (I) plastic cover over the top of the raised garden bed.

Step 2 - Connect the four (A)+(B) ensembles with four (C) corners . Use (D) nuts, screws and washers by placing them in the first row of holes , as shown in the images attached below. Cover the second row of corner holes with (J) hole covers.

Step 3 - Connect (H) support bars three by three by using (G) threaded screws. One of the resulting support bars will be connected to row 2 and the other one to row 3 on the inside of the U-strip bars. Use (D) screws and washers to connect the support bars.
